2 Inch LCD Display 600 Cd/M2 Monochrome LCD Module 160x160 With Serial Port Interface
| Place of Origin | China |
| Brand Name | HuaXianJing |
| Certification | ISO14001/ISO9001/IATF16949 |
| Model Number | HXJLCM160160G-96 |
2 Inch LCD Display
,LCD Display 600 Cd/M2
,Monochrome LCD Module 160x160
This 2 inch Monochrome LCD Display is engineered for demanding applications. Featuring a 160×160 resolution dot matrix display with 600 cd/m² brightness, it delivers clear visibility even in direct sunlight or bright industrial environments. The serial port interface simplifies integration with microcontrollers and processing units. Powered by the reliable UC1698 driver IC, it operates in extreme temperatures down to -40°C.
- 160×160 resolution for crisp information display
- 600 cd/m² brightness for excellent visibility in harsh lighting
- Serial port interface for easy device integration
- UC1698 driver IC for reliable performance
- Operates in temperatures from -45°C to 85°C
Displays meteorological data (temperature, humidity, wind speed) in compact installations. High brightness ensures readability in sunlight, while the wide temperature range maintains functionality in winter conditions.
Shows test results and equipment status in field applications. Compact size and high brightness make it ideal for portable measurement devices used in various industrial environments.
Displays critical information (call signs, frequency settings) in battlefield conditions. The rugged design and extreme temperature tolerance ensure reliable operation in harsh environments.
| Parameter | Value |
|---|---|
| Display Type | Monochrome LCD Display |
| Outline Size | 83.8×76.5×9.6mm |
| Active Area | 54.38×54.38mm |
| Resolution | 160×160 |
| Storage Temperature | -40°C to 70°C |
| Operating Temperature | -45°C to 85°C |
| Interface | Serial port |
| Voltage | 3.3V |
| Driver IC | UC1698 |
| Luminance | 600 cd/m² |
