High Resolution OLED Display Module 12 Pin OLED Display 0.96 Inch Driver IC SSD1317
|
High Resolution OLED Display Module 12 Pin OLED Display 0.96 Inch Driver IC SSD1317
| Place of Origin | China |
| Brand Name | HuaXianJing |
| Certification | ISO14001/ISO9001/IATF16949 |
| Model Number | HXJ9696TSWXG04 |
Product Details
Name:
OLED Display Module
Screen Size:
0.96 Inch OLED Display Module
Panel Size:
24.0*25.7*1.2mm
Viewing Area:
19.26*19.26mm
Display Resolution:
96X96 Pexels
Pixel Arrangement:
SPI
Driver Ic Model:
SSD1317
Number Of Pins:
12 PIN
Highlight:
High Resolution OLED Display Module
,OLED Display Module 12 Pin
,OLED Display 0.96 Inch
Payment & Shipping Terms
Minimum Order Quantity
1000
Price
Negotiated
Packaging Details
blister+foam box+bubble bag+inside carton+master carton
Delivery Time
5weeks~8weeks
Payment Terms
T/T
Supply Ability
100K per month
Product Description
High Resolution OLED Display Module 12 Pin OLED Display 0.96 Inch Driver IC SSD1317
0.96 inch OLED display module 12PIN SPI interface 96x96 resolution white display driver IC SSD1317
The 0.96 inch OLED display module is a compact yet powerful visual solution. It features a 12PIN SPI interface, which enables seamless and rapid data transfer, making it highly compatible with a wide range of microcontrollers. With a 96x96 resolution, this white-display module offers a clear and sharp visual experience. Powered by the SSD1317 driver IC, it ensures stable and reliable operation for various applications.
The 0.96 inch OLED display module is a compact yet powerful visual solution. It features a 12PIN SPI interface, which enables seamless and rapid data transfer, making it highly compatible with a wide range of microcontrollers. With a 96x96 resolution, this white-display module offers a clear and sharp visual experience. Powered by the SSD1317 driver IC, it ensures stable and reliable operation for various applications.
Product Features
- High-Resolution Visuals: The 96x96 resolution provides significant detail with crisp text and clear graphics for complex visual content.
- SPI Interface: 12PIN SPI interface enables fast communication for real-time data visualization applications.
- Stable Driver IC: SSD1317 driver IC optimizes power consumption while ensuring smooth operation and extended module lifespan.
- Compact Size: Space-efficient 0.96 inch design ideal for integration into small-scale electronic devices.
Applicable Scenarios
- Miniature Electronics: Perfect for compact devices like MP3 players and digital recorders with clear display of information.
- Smart Sensor Displays: Shows real-time sensor data in smart home applications with rapid SPI updates.
- Wearable Tech Accessories: Displays battery levels, connection status, and notifications with high visibility in various lighting conditions.
Product Specifications
| Panel Name | 0.96 inch OLED display module |
|---|---|
| Dimensions | 24.0*25.7*1.2mm |
| Viewing area size | 19.26*19.26mm |
| Resolution | 96X96 |
| Working temperature | -30°C~+70°C |
| Storage temperature | -40°C~+80°C |
| Pins | 12 pin |
| Interface | SPI |
| Driver IC | SSD1317 |
Technical Drawing
