800x600 10.4 Inch TFT LCD Touch Screen Resistive LCD Display 60pin 24bit RGB Interface
|
800x600 10.4 Inch TFT LCD Touch Screen Resistive LCD Display 60pin 24bit RGB Interface
| Place of Origin | China |
| Brand Name | HuaXianJing |
| Certification | ISO14001/ISO9001/IATF16949 |
| Model Number | HXJ800600TFT10.4(RTP) |
Product Details
Backlight Luminance:
250Cd/m2
Screen Size:
10.4 Inch Resistive Touch LCD
Panel Size(mm):
228.4*175.4*5.9
Viewing Area(mm):
213.2*160.4
Display Resolution:
800x600 Pexels
Interface:
24bit RGB
Driver Ic Model:
STM32/RA8875
Touch Mode:
Resistive
Highlight:
RGB Interface TFT LCD Touch Screen
,TFT LCD Touch Screen 800x600
,24bit 10.4 Inch TFT Touch Screen
Payment & Shipping Terms
Minimum Order Quantity
1000
Price
Negotiated
Packaging Details
blister+foam box+bubble bag+inside carton+master carton
Delivery Time
5weeks~8weeks
Payment Terms
T/T
Supply Ability
100K per month
Product Description
800x600 10.4 Inch TFT LCD Touch Screen Resistive LCD Display 60pin 24bit RGB Interface
Product Description
10.4 inch resistive touch LCD 60pin 24bit RGB interface driver IC STM32/RA8875 resolution 800*600, 250 brightness
The 10.4 inch resistive touch LCD is a robust and versatile display solution. It is equipped with a 60-pin 24-bit RGB interface, which enables high-speed data transfer and supports rich color depth for vivid and accurate visual representation. With a resolution of 800×600 pixels, it offers clear and detailed imagery. The display has a brightness of 250 nits, providing good visibility in normal indoor lighting conditions. It can be driven by either STM32 or RA8875 ICs, ensuring stable operation and compatibility with a wide range of systems.
Product Features
- Resistive Touch Technology: The resistive touch panel allows for precise touch input, even with gloved hands or using a stylus. It is highly durable and suitable for applications where ruggedness is required.
- High-Speed 60-pin 24-bit RGB Interface: Facilitates rapid data transfer, enabling smooth display of high-quality graphics and video content. The 24-bit color depth ensures a wide gamut of colors for a more realistic visual experience.
- Reliable Driver IC Options: The availability of both STM32 and RA8875 driver ICs offers flexibility in system integration. These ICs provide stable driving performance, accurate color control, and efficient power management.
- Optimal Resolution and Brightness: The 800×600 resolution is sufficient for presenting detailed information, while the 250-nit brightness level makes the screen visible in typical indoor environments, such as offices, classrooms, and industrial control rooms.
Applicable Scenarios
- Industrial Control Systems: In industrial settings, the resistive touch feature, combined with the durability of the display, makes it suitable for use in control panels. Operators can easily interact with the system to monitor and adjust production processes, view real-time data, and manage machinery.
- Medical Equipment: In medical devices, such as patient monitors and diagnostic equipment, the precise touch input and clear display are crucial. The display can show important medical data, images, and user-interface elements, and the resistive touch technology is hygienic and easy to clean.
- Outdoor Information Kiosks: Although the brightness is more suitable for indoor use, in shaded outdoor areas or with proper protection, the 10.4 inch display can be used in kiosks to provide information to the public. The resistive touch screen can withstand harsh environmental conditions better than some other touch technologies.
- Educational Tools: In classrooms, the display can be used as an interactive teaching aid. Teachers can use it to display educational materials, conduct interactive lessons, and students can interact with the content, enhancing the learning experience.
Product Parameter
| Panel Name | 10.4 inch resistive touch LCD Display |
|---|---|
| Dimensions | 228.4*175.4*5.9mm |
| Viewing area size | 213.2*160.4mm |
| Backlight Luminance | 250Cd/m2 |
| Resolution | 800*600 |
| Working temperature | -20°C~+70°C |
| Storage temperature | -30°C~+80°C |
| Interface | 24bit RGB |
| Driver IC | STM32/RA8875 |
| Touch mode | Resistive |
Drawing
