1.77" QQVGA Compact LCD Display With 2 White LED Backlighting
Contact Person : Mr. Zhu
Phone Number : +8613760373914
| Place of Origin: | ShenZhen, China | Brand Name: | WellDA(OEM) |
|---|---|---|---|
| Certification: | ROHS、ISO9001、CE | Model Number: | H028HQ40E2543 |
|
Detail Information |
|||
| Keywords: | 2.8 Inch Small LCD Display | Size: | 2.8inch |
|---|---|---|---|
| Resolution: | 240(horizontal)*320(Vertical) | Interface: | RGB |
| Connect Type: | Connector | Display Colors: | 65K |
| Technology Type: | A-Si | Pixel Pitch (mm): | 0.180x 0.180 |
| Pixel Configuration: | R.G.B.Stripe | Display Mode: | Normally White |
| Driver IC: | ST7789V | Viewing Direction: | 6 O’clock |
| Gray Scale Inversion Direction: | 12 O’clock | LCM (W X H X D) (mm): | 50*69.2*2.3 |
| Active Area(mm): | 43.2*57.6 | With /Without TSP: | Without |
| Weight (g): | 13 G | LED Numbers: | 4LEDs |
Product Description
Unleash Vibrant Visuals With The 2.8 Inch Small LCD Display 65K Color Display
Small Lcd Display Description:
Transform your visual experience with our 2.8 Inch Small LCD Display. This compact display boasts a high resolution of 240(horizontal)*320(vertical) pixels, ensuring your images and graphics are rendered with exceptional clarity and detail. Harnessing the power of the RGB interface, it guarantees seamless data transfer, contributing to the smooth functioning of your display.
Not just high-resolution, this display also brings to life impressive 65K colors, making your visuals more vibrant than ever. Backed by A-Si technology and featuring a pixel configuration of R.G.B.Stripe, it guarantees vivid images that captivate your audience. It's built with a pixel pitch of 0.180x 0.180mm, further enhancing the sharpness of the display.
The 2.8 Inch Small LCD Display is powered by the ST7789V driver IC and operates in the Normally White display mode. With a viewing direction of 6 O'clock and a gray scale inversion direction of 12 O'clock, it ensures optimal visibility.
Despite its small size, it offers a generous active area measuring 43.2*57.6mm. It's lightweight at 13g and fitted with 4 LEDs that enrich the brightness, making it perfect for various applications. The 2.8 Inch Small LCD Display, even without TSP, promises a superior visual experience in a compact package.
Small Lcd Display Applications:
1. Industrial Applications: In industrial settings, the Small LCD Display is used in control panels, handheld instrumentation, testing equipment, and many others due to its durability and ability to operate in harsh conditions. Their ability to withstand extreme temperatures and deliver clear images makes them ideal for such environments.
2. Automotive Applications: In automotive electronics, Small LCD Displays are used in on-board diagnostics systems, GPS navigation systems, rear-view cameras, and digital speedometers. Their high brightness and contrast ratio ensure excellent readability even under bright ambient light conditions.
Small Lcd Display Parameters:
| Keywords: | 2.8 Inch Small LCD Display | Size: | 2.8inch |
|---|---|---|---|
| Resolution: | 240(horizontal)*320(Vertical) | Interface: | RGB |
| Connect Type: | Connector | Display Colors: | 65K |
| Technology Type: | A-Si | Pixel Pitch (mm): | 0.180x 0.180 |
| Pixel Configuration: | R.G.B.Stripe | Display Mode: | Normally White |
| Driver IC: | ST7789V | Viewing Direction: | 6 O’clock |
| Gray Scale Inversion Direction: | 12 O’clock | LCM (W X H X D) (mm): | 50*69.2*2.3 |
| Active Area(mm): | 43.2*57.6 | With /Without TSP: | Without |
| Weight (g): | 13 G | LED Numbers: | 4LEDs |
