1.7 Inch STN LCD Display 12 Pin Graphical Display LCD Serial Port Connection
| Place of Origin | China |
| Brand Name | HuaXianJing |
| Certification | ISO14001/ISO9001/IATF16949 |
| Model Number | HXJ12864159 |
1.7 Inch STN LCD Display
,STN LCD Display 12 Pin
,Graphical Display LCD
1.7 inch STN LCD Display UC1701 driver IC 12pin serial port connection 350 brightness 128x64 resolution forward display graphic dot matrix
This 1.7-inch STN LCD Display presents a highly functional visual solution designed to meet the demands of various applications. With a resolution of 128 x 64 and a graphic dot matrix layout, it is capable of clearly presenting a wide range of visual content, from simple icons and symbols to basic text messages. The forward display technology ensures that the images and text are vividly shown, providing excellent readability. Its 350 brightness level offers enhanced visibility, making it suitable for use in both indoor and moderately lit outdoor environments. The 12-pin serial port connection simplifies connectivity, allowing for easy integration into different electronic systems, reducing wiring complexity and saving space. Driven by the reliable UC1701 driver IC, it guarantees stable and consistent display performance, ensuring that the screen functions flawlessly to deliver the necessary visual cues.
- 128 x 64 resolution with graphic dot matrix for versatile visual display.
- Forward display for sharp and clear image and text rendering.
- 350 brightness for good visibility in diverse lighting conditions.
- 12-pin serial port connection for convenient and space-saving integration.
- UC1701 driver IC for reliable operation.
Smart Home Thermostats: The 1.7 inch size fits neatly into compact housing. The graphic dot matrix can display temperature settings, modes, and system alerts. The forward display ensures easy readability, while the 350 brightness is suitable for living spaces. The 12-pin serial port connects easily to control boards.
Portable Electronic Organizers: Displays calendar events, to-do lists, and contact information clearly. The 128 x 64 resolution and graphic dot matrix present details effectively. Readability is maintained in various lighting conditions, and the 12-pin connection integrates with motherboards.
Handheld Game Consoles: Handles simple game graphics, scores, and instructions. The forward display and 350 brightness enhance gaming experiences. The resolution is sufficient for engaging visuals, and the serial port integrates seamlessly with console circuitry.
| Name | 1.7 inch STN LCD Display |
|---|---|
| Outline size | 41.00*33.10*3mm |
| Active Area | 33.26*20.46mm |
| Resolution | 128x64 |
| Storage temperature | -20°C~+70°C |
| Working temperature | -30°C~+80°C |
| Interface | Serial port |
| Driver IC | UC1701 |
| Luminance | 350cd/m2 |
| Display mode | FSTN/Positive/Transflective |
