Custom Size 2.42 Inch OLED LCD Display 8 Bit Resolution 128x64 With PCBA Board
|
Custom Size 2.42 Inch OLED LCD Display 8 Bit Resolution 128x64 With PCBA Board
| Place of Origin | China |
| Brand Name | HuaXianJing |
| Certification | ISO14001/ISO9001/IATF16949 |
| Model Number | HXJ128640242V30 |
Product Details
Screen Size:
2.42 Inch OLED Display Module
Panel Size:
70.5*49.6*5.9mm
Viewing Area:
57.01*29.50mm
Display Resolution:
128*64 Pexels
Pixel Arrangement:
8-bit Parallel/SPI/I2C
Driver Ic Model:
SSD1309
Number Of Pins:
20 PIN
Highlight:
PCBA board OLED LCD display
,Custom Size OLED LCD display
,2.42 inch OLED LCD display
Payment & Shipping Terms
Minimum Order Quantity
1000
Price
Negotiated
Packaging Details
blister+foam box+bubble bag+inside carton+master carton
Delivery Time
5weeks~8weeks
Payment Terms
T/T
Supply Ability
100K per month
Product Description
Custom Size 2.42 Inch OLED LCD Display 8 Bit Resolution 128x64 With PCBA Board
The 2.42 inch OLED LCD display is a versatile and high-performance visual solution. It comes equipped with multiple interface options, including 8-bit parallel port, SPI, and I2C, providing flexibility for seamless integration into a wide range of systems. With a resolution of 128×64 pixels, it offers clear and sharp visual output, suitable for displaying various types of information. The display is powered by the SSD1309 driver IC, ensuring stable operation and accurate image rendering. Additionally, it is paired with a PCBA board, which simplifies the installation process and enhances the overall reliability of the product.
Product Features
- Multiple Interface Options: The availability of 8-bit parallel port, SPI, and I2C interfaces allows for easy connection to different microcontrollers and host devices, accommodating diverse application requirements.
- High-Resolution Display: The 128×64 pixel resolution ensures that text and graphics are presented with clarity, delivering a detailed viewing experience.
- Reliable SSD1309 Driver IC: The SSD1309 driver IC guarantees stable performance, consistent color representation, and efficient power management, contributing to the longevity and quality of the display.
- Integrated PCBA Board: The included PCBA board streamlines the installation process, reducing the need for complex wiring and component assembly. It also helps in protecting the internal components, enhancing the overall durability of the product.
Applicable Scenarios
- Wearable Devices: In smartwatches and fitness trackers, the 2.42-inch OLED display can show time, fitness data, and notifications clearly. Its multiple interfaces make it easy to integrate with the device's main board, while the compact size and low power consumption are ideal for wearable applications.
- Industrial Control Panels: For small-scale industrial control systems, this display can be used to show real-time data, status indicators, and control commands. The reliable performance and high-resolution output ensure accurate information delivery in industrial environments.
- Educational Electronics: In educational kits and DIY projects, the display's multiple interfaces and easy-to-use nature make it a great choice for teaching students about display technology, embedded systems, and programming. The included PCBA board simplifies the setup process for beginners.
- Portable Electronic Gadgets: In devices like mini-game consoles, portable media players, and handheld scanners, the 2.42-inch OLED display provides an engaging visual interface. The integration with the PCBA board helps in optimizing the device's internal layout and functionality.
Product Parameter
| Panel Name | 2.42Inch OLED Display |
|---|---|
| Dimensions | 70.5*49.6*5.9mm |
| Viewing area size | 57.01*29.50mm |
| Display mode | white |
| Resolution | 128*64 |
| Working temperature | -20°C~+70°C |
| Storage temperature | -30°C~+80°C |
| Interface | 8-bit parallel/SPI/I2C |
| Driver IC | SSD1309 |
Drawing
